Datasources - Complete Guide

🔌 Connect Your Data in Minutes

25+ Built-in Connectors · Secure Connection Management · Real-time Testing

---

📋 Table of Contents

• What are Datasources?
• Supported Data Sources
• Creating a Datasource
• Datasource Configuration
• Testing Connections
• Managing Datasources
• Security & Encryption
• Troubleshooting
• Best Practices

---

What are Datasources?

Datasources are connection configurations that allow Jet Admin to communicate with external systems. They serve as the foundation for all data operations in the platform, enabling you to:

• 📊 Query databases for dashboard visualizations
• 🔄 Fetch data for workflow automations
• 📝 Write data back to external systems
• 🔗 Integrate with third-party services

Key Features

• Unified Interface - Consistent API across all connector types
• Secure Storage - Encrypted credentials at rest
• Connection Pooling - Optimized database connections
• Real-time Testing - Validate connections before saving
• SSH Tunneling - Connect to private networks (coming soon)
• Cloning - Duplicate configurations for different environments

---

Supported Data Sources

Jet Admin supports 25+ data sources across multiple categories:

💾 Databases

Database	Status	Features
PostgreSQL	✅ Stable	Query, Table Manager, Triggers
MySQL	✅ Stable	Query, Table Manager
MongoDB	✅ Stable	Query, Aggregation
MS SQL Server	✅ Stable	Query, Stored Procedures
SQLite	✅ Stable	Query, Local Files
CockroachDB	✅ Stable	Query, Distributed SQL
Oracle	🧪 Beta	Query, PL/SQL
Redis	🧪 Beta	Key-Value Operations
Neo4j	🧪 Beta	Cypher Queries

☁️ Cloud Services

Service	Status	Features
Google BigQuery	✅ Stable	SQL Queries, Data Export
Google Sheets	✅ Stable	Read/Write, Real-time Sync
Google Analytics	✅ Stable	Reports, Real-time Data
Firestore	✅ Stable	Query, Document Operations
Supabase	✅ Stable	Query, Real-time Subscriptions
Airtable	✅ Stable	Query, Record Operations
Amazon S3	✅ Stable	File Upload/Download
Elasticsearch	✅ Stable	Search, Aggregations

🔗 APIs & Messaging

Service	Status	Features
REST API	✅ Stable	Custom Endpoints, Auth
GraphQL	✅ Stable	Queries, Mutations
Slack	✅ Stable	Send Messages, Channels
Twilio	✅ Stable	SMS, Voice, WhatsApp
SendGrid	✅ Stable	Email Templates
Stripe	✅ Stable	Payments, Customers
Jira	✅ Stable	Issues, Projects
Notion	✅ Stable	Pages, Databases
RabbitMQ	🧪 Beta	Publish/Consume

---

Creating a Datasource

Step-by-Step Guide

1. Navigate to Datasources

From the Jet Admin sidebar, click on Datasources to open the datasource management page.

2. Click "Create Datasource"

Click the Create Datasource button in the top-right corner to open the datasource catalog.

3. Choose a Connector

Browse or search through the available connectors. They're organized by category:

┌─────────────────────────────────────────┐
│  📊 Databases      ☁️ Cloud Services    │
│  🔗 APIs           📧 Messaging         │
└─────────────────────────────────────────┘

4. Configure Connection

Fill in the connection details specific to your datasource type.

Example: PostgreSQL Configuration

┌────────────────────────────────────────────┐
│  PostgreSQL Connection                     │
├────────────────────────────────────────────┤
│  Datasource Title:  [Production DB       ] │
│  Host:              [db.example.com      ] │
│  Port:              [5432                ] │
│  Database:          [myapp_production    ] │
│  Username:          [admin               ] │
│  Password:          [•••••••••           ] │
│                                            │
│  [✓] Use SSL                              │
│  [ ] Require SSL Certificate              │
└────────────────────────────────────────────┘

5. Test Connection

Before saving, click Test Connection to verify the credentials work correctly.

6. Save Datasource

Once the test succeeds, click Save Datasource to persist the configuration.

---

Datasource Configuration

Common Configuration Fields

Most datasources share these common fields:

Field	Type	Required	Description
Datasource Title	String	✅	Human-readable name for identification
Datasource Type	String	✅	Connector type (postgresql, restapi, etc.)
Tags	Array	❌	Organizational tags for filtering
Description	String	❌	Notes about the datasource's purpose

Database-Specific Configuration

PostgreSQL / MySQL

{
  datasourceType: 'postgresql',
  datasourceTitle: 'Production Database',
  datasourceOptions: {
    host: 'localhost',
    port: 5432,
    database: 'myapp',
    username: 'admin',
    password: 'secret',
    ssl: {
      enabled: true,
      rejectUnauthorized: false
    },
    pool: {
      min: 2,
      max: 10
    }
  }
}

MongoDB

{
  datasourceType: 'mongodb',
  datasourceTitle: 'Analytics DB',
  datasourceOptions: {
    connectionString: 'mongodb://user:pass@host:27017/dbname',
    database: 'analytics',
    options: {
      useNewUrlParser: true,
      useUnifiedTopology: true
    }
  }
}

API Configuration

REST API

{
  datasourceType: 'restapi',
  datasourceTitle: 'Payment Gateway',
  datasourceOptions: {
    baseUrl: 'https://api.stripe.com/v1',
    authentication: {
      type: 'bearer',
      token: 'sk_test_...'
    },
    headers: {
      'Content-Type': 'application/json',
      'Accept': 'application/json'
    },
    timeout: 30000
  }
}

GraphQL

{
  datasourceType: 'graphql',
  datasourceTitle: 'GraphQL API',
  datasourceOptions: {
    endpoint: 'https://api.example.com/graphql',
    authentication: {
      type: 'header',
      headerName: 'Authorization',
      headerValue: 'Bearer token123'
    },
    defaultQuery: `
      query GetData($id: ID!) {
        item(id: $id) {
          id
          name
          description
        }
      }
    `
  }
}

Cloud Service Configuration

Google Sheets

{
  datasourceType: 'google_sheets',
  datasourceTitle: 'Marketing Data',
  datasourceOptions: {
    spreadsheetId: '1BxiMvs0XRA5nFMdKvBdBZjgmUUqptlbs74OgvE2upms',
    authentication: {
      type: 'service_account',
      credentials: {
        // Service account JSON key
      }
    }
  }
}

Airtable

{
  datasourceType: 'airtable',
  datasourceTitle: 'Project Tracker',
  datasourceOptions: {
    apiKey: 'keyXXXXXXXXXXXXXX',
    baseId: 'appXXXXXXXXXXXXXX',
    tables: ['Projects', 'Tasks']
  }
}

---

Testing Connections

How Testing Works

When you click Test Connection, Jet Admin:

1. Validates Configuration - Checks required fields
2. Establishes Connection - Attempts to connect to the external system
3. Executes Test Query - Runs a simple query/ping
4. Returns Result - Shows success or detailed error

Test Results

✅ Success

┌─────────────────────────────────────┐
│  ✓ Connection Successful!           │
│                                     │
│  Connected to: postgresql://db:5432 │
│  Database: myapp_production         │
│  Response Time: 45ms                │
└─────────────────────────────────────┘

❌ Failure

┌─────────────────────────────────────┐
│  ✗ Connection Failed                │
│                                     │
│  Error: ECONNREFUSED                │
│  Message: Connection refused        │
│  Host: db.example.com:5432          │
│                                     │
│  Troubleshooting:                   │
│  • Check if the database is running │
│  • Verify firewall settings         │
│  • Confirm credentials are correct  │
└─────────────────────────────────────┘

Common Test Errors

Error	Cause	Solution
ECONNREFUSED	Database not reachable	Check host/port, firewall rules
ETIMEDOUT	Connection timeout	Increase timeout, check network
ER_ACCESS_DENIED	Wrong credentials	Verify username/password
SSL_REQUIRED	SSL not enabled	Enable SSL in connection
DATABASE_NOT_FOUND	Invalid database name	Check database exists

---

Managing Datasources

Datasource List

View all datasources in a searchable, filterable table:

┌──────────────────────────────────────────────────────────────┐
│  Search datasources...              [Filter by Type ▼]      │
├──────────────────────────────────────────────────────────────┤
│  Name              Type        Tags        Last Tested       │
│  ──────────────────────────────────────────────────────────  │
│  Production DB     PostgreSQL  prod, main  2 min ago    ✓   │
│  Analytics         MongoDB     analytics   1 hour ago   ✓   │
│  Stripe API        REST API    payments    1 day ago    ✓   │
│  Marketing Sheets  Google      marketing   1 week ago   ⚠   │
└──────────────────────────────────────────────────────────────┘

Actions

From the datasource list, you can:

• Edit - Update connection details
• Test - Re-test the connection
• Clone - Duplicate for another environment
• Delete - Remove the datasource (with confirmation)

Cloning Datasources

Cloning is useful for creating environment-specific variants:

Production DB (postgresql://prod-db:5432/app_prod)
    ↓ Clone
Staging DB (postgresql://staging-db:5432/app_staging)

Use Cases:

• Development vs Production databases
• Multiple regional instances
• Backup/failover configurations

---

Security & Encryption

Credential Encryption

All sensitive datasource credentials are encrypted at rest:

// Encryption process
const encrypted = encryptCredentials({
  password: 'secret123',
  apiKey: 'key_XXXXX'
});

// Stored in database as:
{
  encrypted: 'a1b2c3d4...',
  iv: 'initialization_vector'
}

Access Control

Datasources are protected by RBAC:

Permission	Description
datasource:list	View datasource list
datasource:read	View datasource details
datasource:create	Create new datasources
datasource:update	Edit existing datasources
datasource:delete	Remove datasources
datasource:test	Test connections

Network Security

Best Practices:

1. Use SSL/TLS - Always enable encrypted connections
2. Restrict IPs - Whitelist Jet Admin server IPs
3. Use Service Accounts - Don't use personal credentials
4. Rotate Keys - Regularly update API keys and passwords
5. Audit Access - Monitor datasource usage logs

---

Troubleshooting

Connection Issues

"Connection Refused"

Symptoms: Test connection fails with ECONNREFUSED

Solutions:

1. Verify the host and port are correct
2. Check if the database/service is running
3. Ensure firewall allows connections from Jet Admin
4. Test connectivity using telnet or nc:

   telnet db.example.com 5432

"Connection Timeout"

Symptoms: Test hangs and eventually times out

Solutions:

1. Check network connectivity
2. Increase timeout in datasource options
3. Verify DNS resolution
4. Check for network proxies

"Authentication Failed"

Symptoms: Connection established but auth fails

Solutions:

1. Double-check username/password
2. Verify the user has correct permissions
3. Check if password expired
4. For APIs, verify the token hasn't expired

SSL/TLS Issues

"SSL Required"

Solutions:

1. Enable SSL in datasource configuration
2. For self-signed certs, disable certificate validation (dev only)
3. Install CA certificate on Jet Admin server

"Certificate Verification Failed"

Solutions:

1. Check certificate hasn't expired
2. Verify certificate chain is complete
3. Ensure hostname matches certificate

Performance Issues

Slow Queries

Solutions:

1. Add database indexes
2. Optimize query logic
3. Increase connection pool size
4. Use read replicas for heavy queries

Connection Pool Exhaustion

Solutions:

1. Increase max pool size
2. Reduce idle timeout
3. Check for connection leaks
4. Monitor active connections

---

Best Practices

Organization

✅ Use Descriptive Names

Good: "Production PostgreSQL - Orders DB"
Bad: "Postgres 1"

✅ Add Tags for Filtering

Tags: ['production', 'orders', 'postgresql']
Tags: ['staging', 'analytics', 'mongodb']

✅ Document Purpose

{
  datasourceTitle: 'Analytics DB',
  description: 'Main analytics database for dashboard metrics. Updated hourly via ETL pipeline.'
}

Security

✅ Use Environment-Specific Credentials

Development: dev_user / dev_pass
Staging: staging_user / staging_pass
Production: prod_user / prod_pass

✅ Enable SSL Everywhere

ssl: {
  enabled: true,
  rejectUnauthorized: true // except for self-signed in dev
}

✅ Rotate Credentials Regularly

• API keys: Every 90 days
• Database passwords: Every 60 days
• Service accounts: Every 180 days

Performance

✅ Configure Connection Pools

pool: {
  min: 2,    // Minimum idle connections
  max: 20,   // Maximum total connections
  idleTimeout: 30000
}

✅ Use Read Replicas

// For read-heavy workloads
readReplicas: [
  'postgresql://replica1:5432/db',
  'postgresql://replica2:5432/db'
]

✅ Set Appropriate Timeouts

timeout: 30000,        // 30s for most queries
queryTimeout: 60000,   // 60s for complex queries
connectionTimeout: 5000 // 5s to establish connection

Monitoring

✅ Test Connections Regularly

• Automated health checks every 5 minutes
• Alerts on consecutive failures

✅ Monitor Usage

• Track query execution times
• Monitor connection pool usage
• Alert on high error rates

✅ Audit Access

• Log all datasource modifications
• Review access patterns monthly
• Remove unused datasources

---

Next Steps

• Data Queries - Build queries using datasources
• Workflow Integration - Use datasources in workflows
• Backend Implementation - Technical details
• Frontend Implementation - UI components

---

Need Help?

API Reference · Troubleshooting Guide · Community Support
